The Universal Audio Volt 2 Max is a 10-in / 4-out desktop USB audio interface designed for recording, production, streaming, and content creation. Combining Universal Audio's Tone Shaping Preamps with onboard Max compression, 32-bit / 192 kHz conversion, Auto-Gain, Clip Protection, and a full-color Smart Display, Volt 2 Max gives you a versatile recording setup with professional sound and hands-on controls.

Two microphone/line inputs provide up to 60 dB of digitally controlled gain, while the front-panel Hi-Z inputs make it easy to connect guitars, basses, and other instruments directly. The Tone Shaping Preamps offer three harmonic character modes—Warmth, Focus, and Shine—while Max Processing provides six compressor presets designed for sources such as vocals, guitar, and bass.

The Volt 2 Max also includes a built-in talkback microphone, two headphone outputs, MIDI I/O, and ADAT/S/PDIF optical input for expanding your setup with additional digital inputs. Its built-in USB hub can power compatible peripherals and MIDI controllers, while loopback functionality makes it well suited for podcasts, livestreams, and other content creation applications.

With USB bus power and class-compliant operation, Volt 2 Max can be used with Mac, Windows, iPad, and iPhone. It also integrates with the UAD Console app and LUNA, and includes a collection of UAD plug-ins, instruments, and third-party software to get your recording setup up and running.

Key Features

• 10-in / 4-out desktop USB audio interface

• 32-bit / 192 kHz A/D and D/A conversion

• Two microphone/line inputs with up to 60 dB of gain

• Tone Shaping Preamps with Warmth, Focus, and Shine modes

• Max Processing with six onboard compressor presets

• Two front-panel 1/4" Hi-Z instrument inputs

• Built-in talkback microphone

• Full-color Smart Display with level and gain-reduction metering

• Auto-Gain and Clip Protection

• ADAT or S/PDIF optical input for digital expansion

• Up to 8 channels of ADAT input at 44.1/48 kHz

• MIDI In and Out via 1/8" TRS mini-jacks

• Two headphone outputs with shared cue mix

• Stereo monitor outputs

• Built-in USB hub for peripherals

• Built-in loopback for streaming and podcasting

• Independent 48V phantom power per microphone channel

• USB bus-powered with USB-C connectivity

• Compatible with Mac, Windows, iPad, and iPhone

• UAD Console and LUNA integration

Specifications

I/O

• Simultaneous I/O: 10-in / 4-out

• Microphone Preamps: 2, up to 60 dB gain

• Monitor Outputs: 1 stereo pair

• Headphone Outputs: 2 stereo outputs with shared cue mix

• USB Host: USB 2.0 Type-C

• USB Hub: 5V DC, 0.5A maximum

• Digital Input: ADAT or S/PDIF optical

• MIDI: In/Out, 1/8" TRS Mini-Jack, MIDI Type A

• Talkback: Built-in microphone

Digital Audio

• Sample Rates: 44.1, 48, 88.2, 96, 176.4, 192 kHz

• Bit Depth: 32-bit

• ADAT: 8 channels at 44.1/48 kHz; S/MUX support for 4 channels at 96 kHz or 2 channels at 192 kHz

• S/PDIF: 2 channels at supported sample rates

Microphone Inputs

• Frequency Response: 20 Hz–20 kHz, ±0.08 dB

• Dynamic Range: 119 dB A-weighted

• THD + Noise: -110 dB (0.0003%)

• Maximum Input Level: +14 dBu

• Input Impedance: 2 kΩ

• Gain: 60 dB

• Phantom Power: +48V, independently switchable

• Connector: XLR/TRS combo

Instrument Inputs

• Frequency Response: 20 Hz–20 kHz, ±0.02 dB

• Dynamic Range: 116 dB A-weighted

• THD + Noise: -108 dB (0.0004%)

• Maximum Input Level: +13 dBu

• Input Impedance: 1 MΩ

• Gain: 60 dB

• Connector: 1/4" TS unbalanced

Line Inputs

• Frequency Response: 20 Hz–20 kHz, ±0.05 dB

• Dynamic Range: 119 dB A-weighted

• THD + Noise: -108 dB (0.0004%)

• Maximum Input Level: +22 dBu

• Input Impedance: 10 kΩ

• Gain: 60 dB

• Connector: 1/4" TRS balanced / TS unbalanced

Monitor Outputs

• Frequency Response: 20 Hz–20 kHz, ±0.05 dB

• Dynamic Range: 126 dB A-weighted

• THD + Noise: -112 dB (0.0003%)

• Maximum Output Level: +20.2 dBu

• Output Impedance: 200 Ω

• Connector: 1/4" TRS balanced

Headphone Outputs

• Frequency Response: 20 Hz–20 kHz, ±0.08 dB

• Dynamic Range: 116 dB A-weighted

• THD + Noise: -103 dB (0.0007%, 300 Ω)

• Maximum Output Power: 45 mW into 32 Ω / 24 mW into 300 Ω

• Connectors: 1/4" and 1/8" TRS stereo

Power

• USB Bus-Powered: Yes

• Typical Power Consumption: 4.1 W

• Maximum Power Consumption: 5.7 W

• Power Switch: Rear panel

• USB-C connectivity

System Requirements

• macOS 12 Monterey or newer

• Windows 10 64-bit or newer

• iPadOS / iOS 16 or newer

• Available USB 2.0 or higher port

• Internet connection required for software downloads

• Compatible with major DAWs including Ableton Live, Logic Pro, Pro Tools, FL Studio, GarageBand, and more

Included Software

• LUNA Digital Audio Workstation

• UA 610 Tube Preamp & EQ Collection

• Century Tube Channel Strip

• Teletronix LA-2A Tube Compressor

• UA 1176 Classic FET Compressor

• Pure Plate Reverb

• Galaxy Tape Echo

• Oxide Tape Recorder

• Vibe Analog Machines

• PolyMAX Synth

• Anthem Analog Synth

• UAD Lion '68 Super Lead Amp

• UAD Showtime '64 Tube Amp

• Topline Vocal Tune

• Melodyne Essential

• Ampeg SVT-VR Classic Bass Bundle

• Virtual Drummer DEEP by UJAM

• Virtual Bassist DANDY by UJAM

• Splice INSTRUMENT

• Prisma – Producer Lab by UVI

• FL Studio Producer Edition, 3 months

• Exclusive Puremix audio education content

Software bundles are subject to change without notice.
